Date of Design

2003

Product

Differential Charge Amp

Assembly ID

5693XXXX

Company

THALES

Function

Intercept Sonar Amplifier

Primary Device

IF3601 + AD797

Technology

8 track/8 space/30 via

PCB Build Specification

2 Layer, 1oz,  MASK, ENIG, FR408

Design Compliance

IPC-A-600/IPC-6012

Contract Manufacturer

PCBCo. (SINGAPORE)

CAD Application

Protel 99SE

Prototype Availability

No
The following products and systems are examples of designs I have created, prototyped and manufactured.
Electronic designs by Steven Howell
         2003

The index includes lab prototypes, final production units, integrated systems and application examples.


There are no classified military designs in this list.
