Date of Design

1999

Product

Video Module for Gatekeeper

Assembly ID

VMOD8C5

Company

Novasar (Lockwood)

Function

Video Overlay and Camera Processor

Primary Device

Fujitsu MB90098A

Technology

6 Track/6 Space/24 Via

PCB Build Specification

4 Layer, 1oz, MASK, ENIG, FR4

Design Compliance

94V0

Contract Manufacturer

Precision Circuits (VIC)

CAD Application

Protel Schedit/PFW2.8

Prototype Availability

Yes
The following products and systems are examples of designs I have created, prototyped and manufactured.
Electronic designs by Steven Howell
         1999

The index includes lab prototypes, final production units, integrated systems and application examples.


There are no classified military designs in this list.
