Date of Design

2016

Product

Power Installation Kit

Assembly ID

PIK060416

Company

Summit Innovations

Function

PTS Timer PSU Installation

Primary Device

NA

Technology

10 track/10 space/28 via

PCB Build Specification

2 Layer, 1oz,  MASK, HASL, FR4

Design Compliance

IPC-A-600/IPC-6012/IPC-610

Contract Manufacturer

General Circuits (China)

CAD Application

Altium Designer R14

Prototype Availability

Yes

Downloads

None
The following products and systems are examples of designs I have created, prototyped and manufactured.
Electronic designs by Steven Howell
The index includes lab prototypes, final production units, integrated systems and application examples.


There are no classified military designs in this list.
