Date of Design
2016
Product
Assembly ID
V01
Company
Novasar
Function
Virtual Hardware Device
Primary Device
Technology
4 track/4 space/18 via
PCB Build Specification
6 Layer, 1oz, MASK, ENIG, FR4
Design Compliance
IPC-A-600/IPC-6012/IPC-610
Contract Manufacturer
Speedy Circuits (Taiwan)
CAD Application
Altium Designer R14
Prototype Availability
Yes
Downloads
Yes
Links
The following products and systems are examples of designs I have created, prototyped and manufactured.
Electronic designs by Steven Howell
The index includes lab prototypes, final production units, integrated systems and application examples.
There are no classified military designs in this list.
