Date of Design

2010

Product

Pool Pad Partner RF Module

Assembly ID

PPPRF

Company

Novasar

Function

Wireless Comms and RTC Functions

Primary Device

DS1302+ PT2249A

Technology

5 track/5 space/24 via

PCB Build Specification

Single Layer, 1oz, MASK, ENIG, FR4

Design Compliance

94V0

Manufacturer

PCB Cart (China)

CAD Application

Altium Designer R10

Prototype Availability

Yes

Downloads

SCHEMATIC - PPPRF1V0 (PDF)
The following designs comprise some of the electronic solutions I have created, implemented, prototyped and prepared for
Electronic designs by Steven Howell
         2010


manufacture. The index includes lab prototypes as well as final production units and examples of their application.


There are no classified military designs in this list.
