Date of Design

2008

Product

Xilinx XC3S1400AN FPGA Module

Assembly ID

DB41.02

Company

ALTIUM

Function

FPGA with SRAM, DRAM and Flash Mem.

Primary Device

XC3S1400AN-4FGG676C

Technology

5 track/5 space/24 via

PCB Build Specification

8 Layer, 1/2oz,  MASK, ENIG, TUC04

Design Compliance

IPC-A-600/IPC-6012/IPC-610

Contract Manufacturer

Speedy Circuits (TAIWAN)

CAD Application

Altium Designer 6.9

Prototype Availability

Yes
The following products and systems are examples of designs I have created, prototyped and manufactured.
Electronic designs by Steven Howell
         2008


The index includes lab prototypes, final production units, integrated systems and application examples.


There are no classified military designs in this list.
