Date of Design

2017

Product

SMT NANO (Summit Mini Timer)

Assembly ID

SMT221017FCC

Company

Summit Innovations

Function

Summit Mini Timer

Primary Device

Xilinx XC6SLX25-2FTG256C

Technology

5 track/4 space/24 via

PCB Build Specification

4 Layer, 1oz,  MASK, HASL, FR4

Design Compliance

IPC-A-600/IPC-6012/IPC-610/FCC

Contract Manufacturer

CNS Precision Assembly (Sydney)

CAD Application

Altium Designer R17

Prototype Availability

Yes

Downloads

None
The following designs comprise some of the electronic solutions I have created, implemented, prototyped and prepared for
Electronic designs by Steven Howell
manufacture. The index includes lab prototypes as well as final production units and examples of their application.


There are no classified military designs in this list.
