Date of Design

2017

Product

PTS + SMT Timing Systems

Assembly ID

VID270917

Company

Summit Innovations

Function

165Mhz 3DB Gain Video Amp + ID

Primary Device

AD8075A + 24C02

Technology

10 track/6 space/24 via

PCB Build Specification

2 Layer, 1oz,  MASK, HASL, FR4

Design Compliance

IPC-A-600/IPC-6012/IPC-610

Manufacturer

General Circuits (China)

CAD Application

Altium Designer R17

Prototype Availability

Yes

Downloads

None
The following designs comprise some of the electronic solutions I have created, implemented, prototyped and prepared for
Electronic designs by Steven Howell
manufacture. The index includes lab prototypes as well as final production units and examples of their application.


There are no classified military designs in this list.


© Copyright 2016 - Images are not to be used without written permission
         2017
