Date of Design
2015
Product
Virtualette Desktop Board
Assembly ID
VDT
Company
Novasar
Function
Desktop development bd for Virtualette
Primary Device
Allwinner A20
Technology
4 track/4 space/18 via
PCB Build Specification
6 Layer, 1oz, MASK, ENIG, FR4
Design Compliance
IPC-A-600/IPC-6012/IPC-610
Contract Manufacturer
General Circuits (CHINA)
CAD Application
Altium Designer R14
Prototype Availability
Yes
Downloads
None
